Automatic Wrap Around Labeller Vacuum Wrap

The Pack Leader PL-501D-VW is a fully automatic wrap-around labeller designed to apply a front and back label to a cylindrical container using a vacuum-wrap belt.

Product Code PL-501D-VW Category Tag

PURCHASE

Request Quote

RENT TO BUY

Ask Now

FINANCE

Get Finance

PURCHASE

Enquire Now

FINANCE

Get Finance

RENT TO BUY

Find Out More

PURCHASE

Enquire Now

PURCHASE

Enquire Now

FINANCE

Get Finance

RENT TO BUY

Find Out More

RENT TO BUY

Find Out More

PURCHASE

Buy Now

RENT

Rent Now

FINANCE

Get Finance

RENT TO BUY

Find Out More

Pack Leader’s PL-501D-VW is a basic PL-501 machine that is supplied with a number of ‘optional extras’ already installed.

In the case of the PL-501D-VW this means that the basic label application system has been replaced by fully automatic application belts that rely on a vacuum on the inside the belt to hold the label whilst it is being applied to the container.

The advantages of this system are that it becomes possible to apply larger labels, at speed, to larger type containers, for example, a 5L can. Whilst capable of applying larger labels the PL501D-VW is just as efficient at applying smaller labels which gives it a versatility that sets it apart from other labellers.

The PL-501D-VW can be customised to suit a large range of applications and this differs from the PL-501D-TC and the PL501D-NL which are PL501 machines that are modified to suit a particular bespoke application. The NL and TC variants can be adapted to cater for different sizes of the same bespoke application, but the opportunities for further adaptation are limited. The PL-501D-VW Labeller is fully customisable to incorporate the usual range of optional inclusions:

  • Conveyor Height can be adjusted from 700mm to 1000mm (not including leveling jacks’ adjustment)
  • Optional Hot Foil Coder for batch & expiry printing on labels
  • Label Applicators Up To 200mm tall for larger labels
  • Poly or stainless steel conveyor slats
  • Optional sensors for clear and metallic labels
  • AI Sensor for orientation labeling
  • Tamper-seal labeling

The PL501D-VW also has a list of additional features that are supplied as standard. You can find details of these under the section entitled “Additional Information”.

Pack Leader products are manufactured under strict ISO 9001 quality control procedures and also strictly tested and certified to the European CE and UL standards.

Voltage 220/110 VAC 50/60 Hz Single Phase
Power 760 VA
Controls Touch Screen
Applicator Height 150 mm
Label Size H:150 mm x L:300 mm Max
Label Roll Size 300mm diameter Max.
Label Roll Core 76mm diameter
Maximum Bottle Diameter 100 mm
Conveyor Width 100 mm
Conveyor Speed 5~23 m/min.
Dispensing Speed 40 m/min. Max
Dispense Driver Stepper Motor
Dimensions 2061mm(L) X 1255 mm (W) X 1236mm (H)
Net Weight Approx. 150 KGS
Make

Automatic Function

Mounting

Label Type

,

  • Adjustments via one-touch screen and label sensors ensure simple set-up of any container
  • Manual label position button ensures labels are placed accurately on container
  • Modular system allows for simple future upgrades to be conducted (i.e. 3-point roller, orientation sensor, spacing wheel, hot-foil coder)
  • Missing-label function ensures no product goes unlabelled
  • Fully synchonrised controls (i.e. label dispensing, wrap-belt, conveyor speeds) ensure consistent labelling
  • Independent positioning systems for the wrap-belt, pressure-pad and label applicator for complete flexibility
  • Toolless operation
  • Label/Product counter system to show overall production progress
  • Pre-count to ensure only the number of required units are produced
  • Memory storage with ability to store 30 different label settings
  • 30 Recallable Memory Spots
  • 8 Synchronised Speeds Selection
  • In Built Instructions And Trouble Shooting
  • Production Counter And Preset Function
  • Auto Labelling Start Up Mode
  • Castors For Easy Relocation
  • Levelling Jacks For Uneven Floors
  • 1 x wrap belt
  • 1 x foam pressure-pad
  • 1 x label application system
